Effortless Live Mixing

LiveTrak’s 12 discrete channels (eight mono plus two stereo) have a 3-band mid-parametric EQ and 16 built-in send effects. Its eight mono channels also have a dedicated compressor. With all these controls plus its 12-segment LED metering, the L-12 offers just what you need for intuitive mixing.

Features at a Glance

12 discrete channels (8 mono plus 2 stereo) with XLR or 1/4-inch connectivity

14-track simultaneous recording, 12-track playback

14-in/4-out USB audio interface connectivity

5 powered headphone outputs, each with a customizable and saveable mix

Add backing/click tracks from your computer to your live mix and recording

RCA and TRS line inputs

48V phantom power (channels 1-4 and 5-8)

Hi-Z connectivity (channels 1 and 2)

26 dB pad (channels 3-8)

Built-in compression control (Channels 1-8)

Digital level meters -48 dB to -0 dB

Master mute button

Low-cut control

Stereo panning

Master and Monitor Outputs A-E

Scene saving function, up to 9 scenes saved at a time

16 built-in delay and reverb effects with adjustable parameters

Built-in slate mic

Class-compliant mode (for iOS compatibility)

SD card input

Built-in metronome

Automatic recording starting/stopping capability

Project protection

Import/export projects with USB 2.0 host port

Latency adjustment for A-to-D conversion

Compatible functions for ZOOM FS01 footswitch
